YCHAIN HDCS3800 3in1 4K image tracking conferencing device



Key Features

l  4K Ultra HD

  Supports 4K Ultra HD resolution for clearer video quality.

l  AI portrait tracking

  Utilizing exclusive Al portrait algorithms, the device can easily track conference participants with a hybrid facial and human form recognition system.

l  3in1 Cam+Mic+Speaker

With just one cable, you can utilize the high-sensitivity array microphone and speaker, along with the 120 degree UHD portrait tracking camera.

l  MIC Array microphone

multiple array microphones for spatial processing of the acoustic environment, it maximizes the elimination of ambient noise and retains only the necessary sound waves.

  l  120° Ultra wide-angle

Featuring a 120-degree ultra wide-angle lens, it can capture more people in medium to small sized meeting rooms.

l  IR Remote control

The remote control allows for easy adjustment of screen size, position, sound, and tracking functions of the EPTZ camera without the need for additional software installation.





Technical Specification



l  Camera

-1/2.8" 8.42M SONY CMOS sensor

-Fixed focus with 120* feld of view

-Aperture : F2.2

-Zoom ratio: 5x digital zoom

l  Features

-4K video calling

-Al intelligent portrait tracking

-HD audio processing

-Circular indicator light

-Removable stand for the main

-Support for 1/4 tripods

-Maximum image transfer rate: 3840x2160 MJPG@30FPS 、3840x2160 H.264@30FPS

l  Microphone

-Full directional beamforming array microphone

-Audio frequency range: 100-24000Hz

-Sensitivity: 22dB@1kHz (0dB=1V/Pa)

-Signal-to-noise ratio: 38dB at 94dB SPL@1kHz

l  Speaker

-White light: normal operation

-Red light: camera on standby

l  Interfaces

-3.94" speaker

-408W

l  System requirements

-DC Power interface

-RJ-45 PoE

-USB Type-C

l  Size(wxHxD)

-Windows@7,8.1, 10, or 11 -MacOS 10.0 or higher version system

l  Camera

-70.5x70.5x370.7mm
